EBC/EBA Knitting Control Panel

Manual Of Linear & Sequential Operation


Welcome Screen

Welcome Screen
  1. In this screen actual time & date will be displayed
  2. On pressing Login button screen No.-2 (Main Menu) will be displayed & operator can access screen No. 3,7,8,9,& 11
  3. On pressing xxxxxxx button it will ask for necessary password to access Screen No. 4, 5, 6 & 10
    If operator enters factory set password i.e. 500 Or 600
    If Password 500 is entered it will allow accessing all screens


Main Menu

Main Menu
  1. In this screen Operator can select any desired screen; The Screen No. 4, 5, 6, & 10 can be accessed only after entering Password-500
  2. On pressing Logout Button password will be de-activated


Machine Control

Machine Control
  1. In this screen Operator can enter all Beam Let off Speed (FZ) in mm/Rack
  2. On pressing button 0 of respective beam the FZ value of respective Beam can be feed
  3. Main Motor Speed will be displayed in Actual Column
  4. Operator can select Linear / Sequential Operation for all the Beam
  5. If operator desires to Switch Off any beam the Value “0” must be entered ,
    Now the above display Indicates that the Machine is In Linear Operation Mode. In this mode Screen No. 12, 13, 14 & 15 cannot be displayed
  6. When machine is in Stop Condition , On pressing Linear button once, Sequential Operation will be selected
  7. In Sequential Operation Operator Can access Screen No.:12,13,14 & 15 by pressing Left /Right arrow button
  8. On pressing Main Menu button operator Can return to Screen No.2
  9. On Pressing M/C Status button operator can reach to screen No.7 to view Machine Status


Set Parameter

Set Parameter
  1. This is the Most Important Screen & operator must take care while entering the Beam Data
  2. In this screen Beam Inner Circumference, Beam Outer Circumference & Beam winding data can be entered,
  3. Once the desired Beam data is entered Operator Must Press Set button of particular beam Only
  4. On pressing Set button Beam data will be moved in actual Parameter (This can be visualize in screen No. 9)
  5. On pressing Main Menu button operator Can return to Screen No.2
  6. On Pressing M/C Status button operator can reach to screen No. 7 & 8 to view Machine Status

This screen is Password Protected (“500”)



Manual Mode

Manual Mode
  1. This Screen is provided to move the Beam in Forward / Reverse direction Manually when the machine is In Stop Condition
  2. The Speed Range can be Set from 1 to 5 in respective beam Column (If “1” is entered the beam will rotate @ 20 RPM, & If “5” is entered the beam will rotate @ 100 RPM
  3. On pressing Main Menu button operator can return to Screen No.2
  4. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status

This screen is Password Protected (“500”)



Offset

Offset
  1. This screen is provided to Offset Yarn Feed (FZ) of individual beam in machine Inching Operation
  2. If “0” entered the Yarn Feed during Inching will be as per actual FZ value of the beam.
  3. On pressing Main Menu button operator can return to Screen No.2
  4. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status

This screen is Password Protected (“500”)



Machine Status 1

Machine Status 1
  1. This Screen will show the fault Indication in the machine
  2. On pressing Main Menu button operator can return to Screen No.2
  3. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status


Machine Status 2

Machine Status 2
  1. This Screen will show the fault Indication in the machine
  2. On pressing Main Menu button operator can return to Screen No.2
  3. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status


Actual Parameter

Actual Parameter
  1. During Running & Stop condition this Screen will show the actual Beam Data of all the beams.
    I.e. Beam Outer Circumference & Beam Winding
  2. On pressing Main Menu button operator can return to Screen No.2
  3. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status


Change Password

Change Password

This Screen will allow entering desired new password, this should be done through Authorized Person Only
& it should be noted In Record Book so that one can refer this value if forgotten

  1. On pressing Main Menu button operator can return to Screen No.2
  2. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status

This screen is Password Protected (“500”)



Time / Total Meter

Time / Total Meter
  1. This screen Shows Machine running Total Time in Min. This Time will be totalized only in Machine Fast running Operation
    The Totalized value Can Be Reset by Pressing Respective Reset Button
  2. The Operator Can Set desired Meter data by entering the desired Meter required
  3. The actual Cumulated Production Value will be shown in Meters & Once the value reached at set value The machine will stopped Indicating “Production Meter Completed”
  4. In this condition the machine will not be Started unless Reset Button is pressed
  5. On pressing Main Menu button operator can return to Screen No.2
  6. On Pressing M/C Status button operator can reach to screen No.7 & 8 to view Machine Status


Beam-1 Sequence

Beam-1 Sequence


Beam-2 Sequence

Beam-2 Sequence


Beam-3 Sequence

Beam-3 Sequence


Beam-4 Sequence

Beam-4 Sequence
